The original problem description is available here.
We deserved a simple one today. I started with a function that applies gravity to the blocks. It orders them in ascending Z order then just runs over the list and pushes each block down as much as possible. The result is a nicely packed jenga tower.
Several helper strucures were introduced to make things easier. I have a Range
and
a Block
with some helpers like IntersectsXY
that tells if the X-Y projection of
two blocks are in cover.
I also created a function that returns the support structure of our model at hand, so that I can tell the upper and lower neighbours of each block easily.
The eye catching Kaboom function goes over the input and selects each block for desintegration. It calculates the number of blocks that start falling when this single block disappears. The result is a list of integers, which can be used to answer both questions for today.
namespace AdventOfCode.Y2023.Day22;
using System;
using System.Collections.Generic;
using System.Linq;
record Range(int begin, int end);
record Block(Range x, Range y, Range z) {
public int Top => z.end;
public int Bottom => z.begin;
}
record Supports(
Dictionary<Block, HashSet<Block>> blocksAbove,
Dictionary<Block, HashSet<Block>> blocksBelow
);
[ProblemName("Sand Slabs")]
class Solution : Solver {
public object PartOne(string input) => Kaboom(input).Count(x => x == 0);
public object PartTwo(string input) => Kaboom(input).Sum();
// desintegrates the blocks one by one and returns how many blocks would
// start falling because of that.
IEnumerable<int> Kaboom(string input) {
var blocks = Fall(ParseBlocks(input));
var supports = GetSupports(blocks);
foreach (var desintegratedBlock in blocks) {
var q = new Queue<Block>();
q.Enqueue(desintegratedBlock);
var falling = new HashSet<Block>();
while (q.TryDequeue(out var block)) {
falling.Add(block);
var blocksStartFalling =
from blockT in supports.blocksAbove[block]
where supports.blocksBelow[blockT].IsSubsetOf(falling)
select blockT;
foreach (var blockT in blocksStartFalling) {
q.Enqueue(blockT);
}
}
yield return falling.Count - 1; // -1: desintegratedBlock doesn't count
}
}
// applies 'gravity' to the blocks.
Block[] Fall(Block[] blocks) {
// sort them in Z first so that we can work in bottom to top order
blocks = blocks.OrderBy(block => block.Bottom).ToArray();
for (var i = 0; i < blocks.Length; i++) {
var newBottom = 1;
for (var j = 0; j < i; j++) {
if (IntersectsXY(blocks[i], blocks[j])) {
newBottom = Math.Max(newBottom, blocks[j].Top + 1);
}
}
var fall = blocks[i].Bottom - newBottom;
blocks[i] = blocks[i] with {
z = new Range(blocks[i].Bottom - fall, blocks[i].Top - fall)
};
}
return blocks;
}
// calculate upper and lower neighbours for each block
Supports GetSupports(Block[] blocks) {
var blocksAbove = blocks.ToDictionary(b => b, _ => new HashSet<Block>());
var blocksBelow = blocks.ToDictionary(b => b, _ => new HashSet<Block>());
for (var i = 0; i < blocks.Length; i++) {
for (var j = i + 1; j < blocks.Length; j++) {
var zNeighbours = blocks[j].Bottom == 1 + blocks[i].Top;
if (zNeighbours && IntersectsXY(blocks[i], blocks[j])) {
blocksBelow[blocks[j]].Add(blocks[i]);
blocksAbove[blocks[i]].Add(blocks[j]);
}
}
}
return new Supports(blocksAbove, blocksBelow);
}
bool IntersectsXY(Block blockA, Block blockB) =>
Intersects(blockA.x, blockB.x) && Intersects(blockA.y, blockB.y);
// see https://stackoverflow.com/a/3269471
bool Intersects(Range r1, Range r2) => r1.begin <= r2.end && r2.begin <= r1.end;
Block[] ParseBlocks(string input) => (
from line in input.Split('\n')
let numbers = line.Split(',','~').Select(int.Parse).ToArray()
select new Block(
x: new Range(numbers[0], numbers[3]),
y: new Range(numbers[1], numbers[4]),
z: new Range(numbers[2], numbers[5])
)
).ToArray();
}
