Visit the Advent of Code website for the problem statement here.

Part 1 and Part 2 differ only in the rules for the small and ultra crucibles. And it turns out those can be represented by just two integers: one for the minimum steps the crucible needs to move forward before it can make a turn (or stop), and an other one that puts an upper limit on the distance it can go in a straight line.

The algorithmic part is a pretty standard graph search implemented with a priority queue. If you've seen one, you've seen them all. We are starting from the top left corner with the only goal state in the bottom right. Since we are minimizing for heatloss, we can use that as the priority of the queue items.

namespace AdventOfCode.Y2023.Day17;

using System;
using System.Collections.Generic;
using System.Linq;
using System.Numerics;
using Map = System.Collections.Generic.Dictionary<System.Numerics.Complex, int>;

record Crucible(Complex pos, Complex dir, int straight);

[ProblemName("Clumsy Crucible")]
class Solution : Solver {

    public object PartOne(string input) => Heatloss(input, 0, 3);
    public object PartTwo(string input) => Heatloss(input, 4, 10);

    // Graph search using a priority queue. We can simply store the heatloss in
    // the priority.
    int Heatloss(string input, int minStraight, int maxStraight) {
        var map = ParseMap(input);
        var goal = map.Keys.MaxBy(pos => pos.Imaginary + pos.Real);
        var q = new PriorityQueue<Crucible, int>();

        // initial direction: right or down
        q.Enqueue(new Crucible(pos: 0, dir: 1, straight: 0), 0);
        q.Enqueue(new Crucible(pos: 0, dir: Complex.ImaginaryOne, straight: 0), 0);

        var seen = new HashSet<Crucible>();
        while (q.TryDequeue(out var crucible, out var heatloss)) {
            if (crucible.pos == goal && crucible.straight >= minStraight) {
                return heatloss;
            }
            foreach (var next in Moves(crucible, minStraight, maxStraight)) {
                if (map.ContainsKey(next.pos) && !seen.Contains(next)) {
                    seen.Add(next);
                    q.Enqueue(next, heatloss + map[next.pos]);
                }
            }
        }
        throw new Exception();
    }

    // returns possible next states based on the rules
    IEnumerable<Crucible> Moves(Crucible c, int minStraight, int maxStraight) {
        if (c.straight < maxStraight) {
            yield return c with {
                pos = c.pos + c.dir,
                straight = c.straight + 1
            };
        }

        if (c.straight >= minStraight) {
            var dir = c.dir * Complex.ImaginaryOne;
            yield return new Crucible(c.pos + dir, dir, 1);
            yield return new Crucible(c.pos - dir, -dir, 1);
        }
    }

    // using a dictionary helps with bounds check (simply containskey):
    Map ParseMap(string input) {
        var lines = input.Split('\n');
        return (
            from irow in Enumerable.Range(0, lines.Length)
            from icol in Enumerable.Range(0, lines[0].Length)
            let cell = int.Parse(lines[irow].Substring(icol, 1))
            let pos = new Complex(icol, irow)
            select new KeyValuePair<Complex, int>(pos, cell)
        ).ToDictionary();
    }
}
