As your probe drifted down through this area, it released an assortment of beacons and scanners into the water. It's difficult to navigate in the pitch black open waters of the ocean trench, but if you can build a map of the trench using data from the scanners, you should be able to safely reach the bottom.
The beacons and scanners float motionless in the water; they're designed to maintain the same position for long periods of time. Each scanner is capable of detecting all beacons in a large cube centered on the scanner; beacons that are at most 1000 units away from the scanner in each of the three axes (x, y, and z) have their precise position determined relative to the scanner. However, scanners cannot detect other scanners. The submarine has automatically summarized the relative positions of beacons detected by each scanner (your puzzle input).
Read the full puzzle.
using System;
using System.Collections.Generic;
using System.Linq;
namespace AdventOfCode.Y2021.Day19;
[ProblemName("Beacon Scanner")]
class Solution : Solver {
public object PartOne(string input) =>
LocateScanners(input)
.SelectMany(scanner => scanner.GetBeaconsInWorld())
.Distinct()
.Count();
public object PartTwo(string input) {
var scanners = LocateScanners(input);
return (
from sA in scanners
from sB in scanners
where sA != sB
select
Math.Abs(sA.center.x - sB.center.x) +
Math.Abs(sA.center.y - sB.center.y) +
Math.Abs(sA.center.z - sB.center.z)
).Max();
}
HashSet<Scanner> LocateScanners(string input) {
var scanners = new HashSet<Scanner>(Parse(input));
var locatedScanners = new HashSet<Scanner>();
var q = new Queue<Scanner>();
// when a scanner is located, it gets into the queue so that we can
// explore its neighbours.
locatedScanners.Add(scanners.First());
q.Enqueue(scanners.First());
scanners.Remove(scanners.First());
while (q.Any()) {
var scannerA = q.Dequeue();
foreach (var scannerB in scanners.ToArray()) {
var maybeLocatedScanner = TryToLocate(scannerA, scannerB);
if (maybeLocatedScanner != null) {
locatedScanners.Add(maybeLocatedScanner);
q.Enqueue(maybeLocatedScanner);
scanners.Remove(scannerB); // sic!
}
}
}
return locatedScanners;
}
Scanner TryToLocate(Scanner scannerA, Scanner scannerB) {
var beaconsInA = scannerA.GetBeaconsInWorld().ToArray();
foreach (var (beaconInA, beaconInB) in PotentialMatchingBeacons(scannerA, scannerB)) {
// now try to find the orientation for B:
var rotatedB = scannerB;
for (var rotation = 0; rotation < 24; rotation++, rotatedB = rotatedB.Rotate()) {
// Moving the rotated scanner so that beaconA and beaconB overlaps. Are there 12 matches?
var beaconInRotatedB = rotatedB.Transform(beaconInB);
var locatedB = rotatedB.Translate(new Coord(
beaconInA.x - beaconInRotatedB.x,
beaconInA.y - beaconInRotatedB.y,
beaconInA.z - beaconInRotatedB.z
));
if (locatedB.GetBeaconsInWorld().Intersect(beaconsInA).Count() >= 12) {
return locatedB;
}
}
}
// no luck
return null;
}
IEnumerable<(Coord beaconInA, Coord beaconInB)> PotentialMatchingBeacons(Scanner scannerA, Scanner scannerB) {
// If we had a matching beaconInA and beaconInB and moved the center
// of the scanners to these then we would find at least 12 beacons
// with the same coordinates.
// The only problem is that the rotation of scannerB is not fixed yet.
// We need to make our check invariant to that:
// After the translation, we could form a set from each scanner
// taking the absolute values of the x y and z coordinates of their beacons
// and compare those.
IEnumerable<int> absCoordinates(Scanner scanner) =>
from coord in scanner.GetBeaconsInWorld()
from v in new[] { coord.x, coord.y, coord.z }
select Math.Abs(v);
// This is the same no matter how we rotate scannerB, so the two sets should
// have at least 3 * 12 common values (with multiplicity).
// 🐦 We can also considerably speed up the search with the pigeonhole principle
// which says that it's enough to take all but 11 beacons from A and B.
// If there is no match amongst those, there cannot be 12 matching pairs:
IEnumerable<T> pick<T>(IEnumerable<T> ts) => ts.Take(ts.Count() - 11);
foreach (var beaconInA in pick(scannerA.GetBeaconsInWorld())) {
var absA = absCoordinates(
scannerA.Translate(new Coord(-beaconInA.x, -beaconInA.y, -beaconInA.z))
).ToHashSet();
foreach (var beaconInB in pick(scannerB.GetBeaconsInWorld())) {
var absB = absCoordinates(
scannerB.Translate(new Coord(-beaconInB.x, -beaconInB.y, -beaconInB.z))
);
if (absB.Count(d => absA.Contains(d)) >= 3 * 12) {
yield return (beaconInA, beaconInB);
}
}
}
}
Scanner[] Parse(string input) => (
from block in input.Split("\n\n")
let beacons =
from line in block.Split("\n").Skip(1)
let parts = line.Split(",").Select(int.Parse).ToArray()
select new Coord(parts[0], parts[1], parts[2])
select new Scanner(new Coord(0, 0, 0), 0, beacons.ToList())
).ToArray();
}
record Coord(int x, int y, int z);
record Scanner(Coord center, int rotation, List<Coord> beaconsInLocal) {
public Scanner Rotate() => new Scanner(center, rotation + 1, beaconsInLocal);
public Scanner Translate(Coord t) => new Scanner(
new Coord(center.x + t.x, center.y + t.y, center.z + t.z), rotation, beaconsInLocal);
public Coord Transform(Coord coord) {
var (x, y, z) = coord;
#pragma warning disable 1717
// rotate coordinate system so that x-axis points in the possible 6 directions
switch (rotation % 6) {
case 0: (x, y, z) = (x, y, z); break;
case 1: (x, y, z) = (-x, y, -z); break;
case 2: (x, y, z) = (y, -x, z); break;
case 3: (x, y, z) = (-y, x, z); break;
case 4: (x, y, z) = (z, y, -x); break;
case 5: (x, y, z) = (-z, y, x); break;
}
// rotate around x-axis:
switch ((rotation / 6) % 4) {
case 0: (x, y, z) = (x, y, z); break;
case 1: (x, y, z) = (x, -z, y); break;
case 2: (x, y, z) = (x, -y, -z); break;
case 3: (x, y, z) = (x, z, -y); break;
}
#pragma warning restore
return new Coord(center.x + x, center.y + y, center.z + z);
}
public IEnumerable<Coord> GetBeaconsInWorld() {
return beaconsInLocal.Select(Transform);
}
}
